NVR Series
- Brand: ANCEND
- Type:
- Price: RMB
- Promotion: RMB ( 0 Customers Bought)
Details：
Key Features：
• Can connect IP camera, IP speed dome camera and DVS; support Onvif protocol;
• Compatible with main brand IP cameras: AXIS, SONY, Panasonic, SANYO, BOSCH, SAMSUNG, Honeywell, VIVOTEK, Ambarella, HIKVISION, DAHUA, Histream, Grandstream, TOPSEE, Launch, WISION, HYVISION, WAPA etc.;
•Support megapixel HD network video preview, storage and playback;
• Click any area and zoom in or zoom out on the image by mouse;
• Support digital zooming under preview and playback modes;
• Support search, playback and backup by event;
• Support 4ch playback simultaneously
1. Preview channel can be switched to other channel randomly without changing
the MAC which is convenient for the project construction;
2. The dendritic menu can be moved. Man-machine communication is more direct
and the settings of parameters are more easy and convenient;
3. The mouse roller can realize 15X digital zooming which the enlarged image can
be dragged and moved randomly under preview and playback modes;
4. Immediate snapshot and immediate view; the picture will be stored in an
independent area in the HDD;
5. The recording playback is shown by time bar and different color represents
different recording type. It is very fast and easy to find check the recording;
6. Recording backup can be accurate to second. Any time period of backup is
available;
7. The recording files in the USB disk can play directly in the playback interface
while the snapshot pictures can be viewed directly;
8. With 3G, WIFI wireless connection functions;
9. Standard resolution which can be adjusted according to the display device in
order to get the best image quality;
10. Adopt HDD sequence writing method and the data is written from 0 track which
increase 2.5X lifetime of the HDD.
|
Operating System |
Embedded LINUX operating system |
|
|
Image Code Control |
Image code quality adjustable, variable bitstream and constant bitstream optional |
|
|
Dual Stream |
Each channel can set main stream and sub stream |
|
|
Video Standard |
1080P(1920×1080)30fps/960P/(1280×960)/720P(1280×720)30fps |
|
|
Monitoring Image Quality |
1080P(1920×1080) / 960P/(1280×960)/720P(1280×720) |
|
|
Image Motion Detection |
Each screen can set mutiple detection areas and set 6-level sensitivity（IPC Support） |
|
|
Recording Playback Quality |
4ch 720P playback in 8ch 720P mode;1ch 1080P playback in 8ch 1080P mode |
|
|
Region Cover |
Every channel can set 4 cover regions（IPC Support） |
|
|
Recording Mode |
Support manual , auto, dynamic detection, alarm trigger record mode (Partly needs IPC Support) |
|
|
Backup Way |
Support U disk, USB mobile HDD, USB DVD-RW. network storage and backup |
|
|
Operation Way |
Mouse |
|
|
Local Login |
User name and password |
|
|
Recording Storage |
Local HDD, network |
|
|
External Ports |
Video Input |
①8×(1280*720) IP camera;4ch playback |
|
②8×(1920*1080) IP camera;1ch playback |
||
|
Audio Input |
4ch network audio input |
|
|
Video Output |
1ch VGA+1ch HDMI |
|
|
Audio Output |
1ch RCA auxiliary Output |
|
|
Network Port |
1 RJ45,10M/100M self-adaptive LAN port |
|
|
USB Port |
3 USB 2.0 ports(one on front panel, two on rear panel) |
|
|
Wireless Port |
3G，WIFI |
|
|
HDD |
HDD Port |
1 SATA HDD Port |
|
MAX Capacity |
Each port supports MAX 4TB HDD |
|
|
Mobile Surveillance |
Support( iPhone, Windows Mobile, BlackBerry, Symbian, Android) smart phone |
|
|
Power Supply |
12V2.6A |
|
|
Power Consumption |
≤25W（without HDD） |
|
|
Working Temperature |
-10℃～＋55℃ |
|
|
Working Humidity |
10％-90％ |
|
|
Dimension |
Equipment：260mm×220mm×43mm， Packing：355mm×255mm×88.5mm |
|
|
Weight(without HDD) |
N.W.：1.5Kg；With packing：2.4Kg |
|
|
Outside Carton |
10 pcs/carton. 525mm×455mm×365mm； Weight：25 Kg |
|
|
Installation Way |
Desktop Installation |
|
